SW1015
SafeWay’s ORv3 Blind Mate Quick Connector supports both radial and angular misalignment capability, featuring a lower average mate force than other brands, and optimized flow performance for efficient cooling.
Developed as part of the Open Compute Project initiative for standard data center infrastructure solutions, the BMQC is specifically designed for rack integration and interoperability. The SafeWay BMQC is fully interchangeable with other OCP Inspired™ or OCP Accepted™ ORv3 Blind Mate Quick Connectors.
The Open Compute Project is a collaborative community dedicated to designing and developing standardized solutions for data center infrastructure. Within this ecosystem, companies like SafeWay, have played a pivotal role in designing a standard spec to be used industry wide.
SW1015
Product Highlights
- Blind mate quick connector designed for rack integrated liquid cooling solutions
- Meets or exceeds dimensional and performance requirements for OCP ORv3 BMQC specification.
- Fully interchangeable with other OCP Accepted™ or OCP Inspired™ ORv3 BMQC couplings.
- Supports up to 5mm of radial misalignment and up to 2.74° of angular misalignment.
- Lower restriction than other brands while maintaining conformance to specification.
- Lower average mate force than other brands.
- Connection Style: Blind Mate, dry break.
- Valve Type: Poppet/O-ring Seal
- Wetted Components: Stainless Steel and EPDM
